No.
|
Item
|
Specification
|
|
|
||||
Steel Structure Parts
|
|
|
|
|
||||
1
|
Roof truss
|
Galvanized steel square tube, material: Q235.
|
|
|
||||
2
|
Steel column
|
Galvanized steel square tube, material: Q235.
|
|
|
||||
3
|
Steel foundation
|
Galvanized U section steel.
|
|
|
||||
Main Part of the House
|
|
|
|
|
||||
1
|
Roof
|
EPS cement/EPS/Mineral wool/Glass wool/PU sandwich panels
|
|
|
||||
2
|
Wall
|
EPS cement/EPS/Mineral wool/Glass wool/PU sandwich panels
|
|
|
||||
3
|
Floor
|
Ceramic floor or wooden floor, thickness:15-18mm
|
|
|
||||
Accessory Parts
|
|
|
|
|
||||
1
|
Windows
|
PVC/aluminum/wooden windows
|
|
|
||||
2
|
Doors
|
Exterior door: steel security door+Inner door: aluminum/wooden door
|
|
|
||||
3
|
Inner wall
|
Wall paper (in choice)
|
|
|
||||
4
|
Electrical accessories
|
Ceiling lights, electric wire and sockets for different countires
|
|
|
||||
5
|
Kitchen fittings
|
Kitchen cabinet with stainless sink
|
|
|
||||
6
|
Toilet
|
Toilet, washing basin and shower head
|
|
|
||||
7
|
Drainage system
|
PVC gutter and PVC downspout
|
|
|
||||
Technical Parameters
|
|
|
|
|
||||
1
|
Wind load
|
0.5KN/㎡, can be adjusted according to climate
|
|
|
||||
2
|
Snow load
|
0.5KN/㎡, can be adjusted according to climate
|
|
|
||||
3
|
Earthquake resistance
|
Up to 9 degree
|
|
|
||||
4
|
Life span
|
Over 35 years lifespan.
|
|
|
Materials of the wall system 16mm metal external wall cladding Its surface is made of 0.42mm colored steel pressed with embossed
pattern;bottom is pasted with dampproof aluminium foil;integrated with PU between the surface and bottom. size: 16mm 12mm metal external wall claddingIts surface is made of 0.42mm colored steel pressed with embossed pattern;bottom is pasted with dampproof aluminium foil;integrated with PU between the surface and bottom. size: 12mmMatal Carved boardIts surface is made of 0.42mm colored steel pressed with embossed pattern;bottom is pasted with dampproof aluminium foil; integrated with PU between the surface and bottom. size: 16mm. effective width 375mm and 385mm |
Size: width:20.32-25.4cm thickness: 0.8mm-1.0mm Normal length: 3.81m weigth:2.2(±0.1kg)/m²
Cement fiber external wall cladding(solid) Size: effective width: 460mm effective thickness: 16mm18mm
Rippled plate Size: effective width:825mm Metal external wall cladding pendant Aluminium alloy belt course |
Insulation material
Glass insulation cotton Used in the wall system and roof system as insulation material.
XPS Used in the wall system and roof system asinsulation material. Building paper Isolate the mositure; mainly used in the wall system and theconnection of wall keel and cement floor. House wrap It is used to let the inside mositure out and protect the inner space fromthe humidity outside.Used in the wall system |
Downspout
•PVC gutter
•Steel gutter Boards •Gypsum board Size: 2.4m*3m; 9.5mm/12mm15mm Used in the inner wall, floor. •Cement fiber board Size: 2.4m*3m; thickness: 9.5mm/12mm/15mm •Wood floor |
