1.Solid Built-up I-beam main frame construction; 2.high strength plate steel; 3.Submerged Arc/welded Frames.
Specification  | ||||
Items  |  Specification  | |||
 Main Steel Frame  |  Column  |  Q235, Q355 Welded H Section Steel  | ||
 Beam  |  Q235, Q355 Welded H Section Steel  | |||
 Secondary Frame  |  Purlin  |  Q235 C and Z purlin  | ||
 Knee brace  |  Q235 Angle Steel  | |||
 Tie Rod  |  Q235 Circular Steel Pipe  | |||
 Brace  |  Q235 Round Bar  | |||
 Vertical and Horizontal Support  |  Q235 Angle Steel, Round Bar or Steel Pipe  | |||
 Maintenance system  |  Roof Panel  |  EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel /Steel Sheet  | ||
 Wall Panel  |  Sandwich Panel / Corrugated Steel Sheet  | |||
 Accessories  |  Window  |  Aluminiumn Alloy Window / PVC Window / Sandwich Panel Window  | ||
 Door  |  Sliding Sandwich Panel Door / Rolling Metal Door   | |||
 Rainspout  |  PVC  | |||
 Live load on Roof  |  In 120kg/Sqm (Color steel panel surrounded)  | |||
 Wind Resistance Grade  |  12 Grades  | |||
 Earthquake-resistance  |  8 Grades  | |||
 Structure Usage  |  Up to 50 years  | |||
 Finishing Options  |  Vast array of colors and textures available  | |||
 Paint Options  |  Alkyd paiting, two primary painting, two finish painting (Primer 、Medium paint 、top coat, epoxy zinc etc.) Or Galvanized.  | |||
